AvosDim motor with override Ø55mm - switch control
Product details
Switch control motor: Use
This roller shutter motor is ideal for installations where a manual alternative is necessary such as entry or exit points. The emergency manual control is operated by crank (optional) either directly into the motor or via internal wall attachment.
Switch control motor: Compatibility
The wired Avosdim Ø55mm motor is suitable for powering all roller shutters with a corresponding curtain weight and roller size. See below for more details.Switch control motor: Configuration
Nm power:
The power needed depends on shutter curtain weight - this can be calculated from the height and width of the visible slat curtain and the weight of relevant slat material. The general ratio for motor power is 1Nm supports 2Kg.
Shutter curtain weight formula:
width (m) x height (m) x weight* (per m2)
* PVC: 4kg/m² or ALU: 4.5kg/m²
Motor adapters:
Adapter sets are supplied with a wheel and a crown. One allows the motor to rotate the roller while the other manages stop limits.
Adapters must correspond to motor brand, diameter, and roller barrel type - if replacing identical motor no adapters are necessary. We stock adaptors for a variety of roller tube shapes including 60mm octagonal, ZF 54mm, ZF 64mm and more.
Motor supports:
Support brackets are also essential. Fixed at one side, they are used to hold the motor head in place so it can power the barrel effectively.
Our selection accounts for the type of motor selected. To choose the correct bracket just reference the roller type and box size (if applicable).
The support suitable for short motors that we offer is QUOTI_QZ04, it is universal, therefore compatible with all types of shutter.
Switch control motor: Specifications
| Power | Motor length* | Speed |
| 80Nm | 782mm | 12 rpm |
*Plus visible motor head of 19mm
Consumption: 230V / 50Hz
Capacity: 22 turns
Motor diameter: 45mm
Safety index: IP44
Certifications: CE, TUV (Germany), VDE (Germany), ROH
Remote control motor: AvosDim technology
AvosDim technology offers a range of remote control motors, developed for those who wish to modernise their shutters or blinds with a high quality motor at an economical price. Compatible with a wide range of remote control and automation, you can enjoy the future now.
Package contents
- Ø55mm wired switch control motor with override (accessories optional)
- 2m VVF 4-core cable - black
- Stop limit adjustment key
- Instruction manual
Instruction manuals
/maxresdefault.jpg"
data-link=""
alt="Setting stop limits on AvosDim motors"
title="Setting stop limits on AvosDim motors"
/>
Information sheet
| Name | AvosDim motor with override |
|---|---|
| SKU | 005219 |
| Sku Fabriquant | 005219 |
| Warranty (years) | 5 |
| Brand | AVOSDIM |
